Cric

Cric is a fully-analogue patchable synthesiser, designed to showcase our approach and attitude towards subtractive sound synthesis. It is not a clone or derivative of a pre-existing musical instrument, nor is it simply our Eurorack modules cased up in a box. Whilst some of Cric’s functionality descends directly from our experience in designing modular synthesiser components, it has been designed as a fully fledged, standalone instrument, which can easily be introduced into an existing electronic music studio, or even form the heart of an entirely new set-up.

Rock solid voltage-controlled oscillators give the user both pitch precision and FM flexibility. A comprehensive filter section affords timbral sculpting from basic filtering to total transformation of incoming tones. Four cyclical function generators can be used as envelopes, LFOs or even audible VCOs. Pin matrix patching allows for the synthesiser to be configured as a standard triple-VCO subtractive synth, or a paraphonic synth, or a drum machine, or a noise box, and so the list goes on. Four inputs and outputs allow for audio processing, external CV control, feedback routing and more - there's even a microphone pre-amp on input 1. Steel casing, Mirrl-clad HIMACS end-cheeks, and hand assembly and testing ensure a rugged and durable build quality.

A user manual for Cric can be found here.

Technical specifications:

Oscillators : Three SSI2131-based analogue VCOs in Recombination configuration, white noise generator
Filter : SSI2164-based 18dB/octave state-mixable analogue VCF, with wave-folding, based on the Timbral Sculptor
Dynamics : SSI2164-based VCAs present in DNA oscillators, filter section and as a standalone VCA
Modulation : Sample and hold + four cyclical function generators offering AD and ASD envelope configuation, cycle mode, and slope and pulse sources
Routing : 24 source x 32 destination active pin matrix allowing for splitting and summing of all signals
I/O : Four DC-coupled inputs and outputs for multi-channel audio and CV use. Microphone pre-amplifier assigned to In 1. Headphone amplifier on Out 1
Dimensions : 550 x 310 x 80 mm, 5.3 kg
Power : +12VDC (centre positive, 2.1mm barrel jack connector), 2.5A, PSU included
