Everything sounds better with compression – whether you need a bit of extra pressure for your drum sounds or just that extra touch to make your modular mix more nimble and tight, the Erica Synths Stereo Compressor will make your live performances a joy. The module is optimized for percussion sounds and will be a great addition to any Erica Synths Drum module rig. The Stereo sidechain can be used to animate melodic layers on the beat and to truly bring your Basslines to life.
Features
- THAT chip-based stereo compressor
- DC coupled sidechain
- Gain, Threshold and Compression Amount (Ratio) settings
- Stereo Link for level detectors
- Bypass switch
- 8 segment output level VU meter
Technical specifications:
Audio input level | -5…+5V |
Threshold | -40dB to +10dB |
Makeup gain | -12dB to +12dB |
Ratio | 1:1 to ∞ |
Power consumption | +60mA, -22mA |
Module width | 10HP |
Module depth | 35mm |
