SPECS & MANUAL / RUMBLE OF ANCIENT TIMES
Sync out voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 V
Minimum syn in voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.2 V
Current input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 mA
Maximum output voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 V
Audio output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 mm jack
Sync out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.5 mm jack
Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4*AAA battaries
Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122 x 136 x 40 mm
Weight (without batteries) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145 g
DISCLAIMER
RoAT uses a PCB as the top panel. The PCBs are produced in an electronics factory using standard production procedures. Due to this, the PCBs may have minor scratches and marks inherent to the manufacturing process. Such small defects will be almost invisible in most cases without a close inspection and will not be accepted as a reason for return or exchange of the product! Obviously, we discard all seriously damaged or defective PCBs and don’t use them for RoAT.
